SPF, DKIM and DMARC Explained: Setup Guide

What is SPF?

SPF (Sender Policy Framework) is a list of the servers allowed to send email on behalf of your domain. It is published as a TXT record on the domain. When a receiving server gets a message, it checks whether the sending server's IP address is on that list.

A typical SPF record:

yourcompany.com.  TXT  "v=spf1 include:_spf.example-provider.com ip4:203.0.113.10 ~all"

What each part means:

• v=spf1 marks this as an SPF record.
• include:... pulls in another service's list of servers, such as your mail hosting provider's.
• ip4:... allows a specific IP address, for example a VPS you send email from.
• ~all asks receivers to treat mail from any other server as suspicious. -all asks them to reject it.

SPF has two important limits. A domain can have only one SPF record; two separate v=spf1 records break SPF entirely. And an SPF check may trigger at most 10 DNS lookups; add too many include mechanisms and SPF returns an error.

SPF is not enough on its own, because it only checks the server that delivered the message. Forwarding can break it, and it does not directly protect the "From" address the reader sees. DKIM and DMARC close those gaps.

What is DKIM?

DKIM (DomainKeys Identified Mail) is a digital signature added to every message you send. The sending server signs the headers and body with a private key, and the matching public key is published in your domain's DNS. The receiving server uses the public key to check the signature. If it matches, the message really came from your servers and was not changed in transit.

A DKIM record is published under a selector on the _domainkey subdomain:

default._domainkey.yourcompany.com.  TXT  "v=DKIM1; k=rsa; p=MIIBIjANBgkqhkiG9w0BAQEFAAOCAQ8AMIIBCgKCAQEA..."

You do not create the key yourself. Your email service generates it and shows you the value to add to DNS. Thanks to selectors, one domain can have several DKIM keys, for example one for your mail hosting and one for your newsletter tool.

DKIM survives forwarding much better than SPF, because the signature travels with the message itself.

What is DMARC?

DMARC (Domain-based Message Authentication, Reporting and Conformance) ties SPF and DKIM together. It does two things:

1. It checks alignment. The domain in the visible "From" address must match the domain that passed SPF or DKIM. That stops an attacker from passing SPF with their own domain while putting yours in the "From" field.
2. It sets a policy and asks for reports. It tells receivers what to do with messages that fail, and asks them to send you reports.

The DMARC record lives on the _dmarc subdomain:

_dmarc.yourcompany.com.  TXT  "v=DMARC1; p=none; rua=mailto:dmarc@yourcompany.com"

The p value is the policy:

• p=none: take no action, just report. The right place to start.
• p=quarantine: send failing messages to spam.
• p=reject: reject failing messages.

The rua address receives daily aggregate reports showing who sends email for your domain and whether it passes. The reports are XML, so use one of the free DMARC report analyzers to read them.

How to set up SPF, DKIM and DMARC

1. List every service that sends email for your domain. Your mail hosting, your website's contact form, your invoicing system, your newsletter tool, your CRM. Forgetting one of these is the most common mistake.
2. Set your MX records. MX records decide which server receives your incoming email. Enter the values from your mail hosting provider and remove old MX records.
3. Create a single SPF record. Combine the include value of every service in one v=spf1 record and end it with ~all.
4. Enable DKIM. Turn on DKIM signing in each service and add the TXT record it gives you. Adding the record is not enough on its own; check that signing is actually switched on.
5. Add DMARC with p=none and choose an address for reports.
6. Test. Send a message to yourself and to a Gmail address. In Gmail, "Show original" lists SPF, DKIM and DMARC as PASS or FAIL. mail-tester.com scores all records in one go.
7. Tighten the policy. Once the reports show every legitimate service passing for a few weeks, move to p=quarantine, then to p=reject.

Common mistakes

• Two SPF records. Adding a second v=spf1 record for a new service instead of editing the existing one. SPF then fails completely.
• Going over 10 lookups. Every include costs at least one lookup and may contain more. Remove services you no longer use.
• Using +all. It allows every server in the world to send as you, which makes SPF pointless.
• Mangling the DKIM key. Long DKIM values sometimes get split or picked up with trailing spaces in DNS panels. Verify the record with a DKIM checker after adding it.
• Starting with p=reject. If you forgot a service, such as your invoicing system, its email is rejected and you only find out when customers complain.
• Sending bulk mail from your business mailbox. Correct records do not fix the reputation damage of mass mailing. Use a service built for newsletters and campaigns.

Authentication is only part of deliverability

Good inbox placement is close to impossible today without SPF, DKIM and DMARC, but they are not enough on their own. Receiving providers also look at the history of the sending IP and domain, message content, blocklists and whether recipients mark your messages as spam. A correct reverse DNS (rDNS) record for the sending IP matters too; on mail hosting, your provider sets that for you.
