What Is an SSH Tunnel? A Port Forwarding Guide

Local forwarding (-L)

It's used to reach a service on your server that only listens on 127.0.0.1 from your own computer. The syntax:

ssh -L [local_port]:[target_host]:[target_port] user@server

Example: Secure access to a database. MariaDB on the server only listens on 127.0.0.1:3306, and port 3306 is closed to the internet:

ssh -L 3307:127.0.0.1:3306 user@203.0.113.10

While this connection is open, you connect to 127.0.0.1:3307 on your own computer with HeidiSQL, DBeaver or another tool; the connection is forwarded, encrypted, to the database on the server. We cover database settings in our How to install MariaDB and How to install PostgreSQL guides.

Example: Access to a web interface. To open a monitoring panel that runs on port 19999 on the server, and that you don't want to expose, in your own browser:

ssh -L 19999:127.0.0.1:19999 user@203.0.113.10

Then open http://127.0.0.1:19999 in your browser.

Reaching another server behind it: The target address doesn't have to be the server itself. You can also tunnel to another machine your server reaches over a private network:

ssh -L 5433:10.8.0.20:5432 user@203.0.113.10

Remote forwarding (-R)

It works in the opposite direction: it connects a port on the server to a service on your own computer. For example, to temporarily show an application you're developing on port 3000 on your own computer through port 8080 on the server:

ssh -R 8080:127.0.0.1:3000 user@203.0.113.10

By default, the remote port only opens on the server's 127.0.0.1 address. For it to be reachable from outside, the GatewayPorts setting in the server's sshd_config file has to be changed; do this only if you know what you're doing, and only temporarily.

Dynamic forwarding (-D): SOCKS proxy

ssh -D 1080 user@203.0.113.10

This command opens a SOCKS proxy at 127.0.0.1:1080 on your own computer. When you enter this address in your browser's proxy settings, your browser traffic goes out to the internet through your server, encrypted. It's useful on untrusted Wi-Fi networks or for services that only allow access from your server's IP address. Traffic leaving your server is your responsibility; for heavy and continuous use, check your provider's usage rules.

Useful parameters

For a connection that runs in the background and only opens a tunnel:

ssh -f -N -L 3307:127.0.0.1:3306 user@203.0.113.10

Persistent tunnels with ~/.ssh/config

Instead of typing long commands every time, save the tunnels you use often in the ~/.ssh/config file on your own computer:

Host db-tunnel
    HostName 203.0.113.10
    User user
    IdentityFile ~/.ssh/id_ed25519
    LocalForward 3307 127.0.0.1:3306
    LocalForward 19999 127.0.0.1:19999
    ServerAliveInterval 30

Now a single command opens both tunnels:

ssh -N db-tunnel

ServerAliveInterval stops an idle connection from being closed by a router or firewall.

Always-on tunnels: If one server needs to stay connected to another through a permanent tunnel, you can run the autossh tool, which reconnects automatically when the connection drops, as a systemd service. To connect several servers to each other permanently, a VPN such as WireGuard is usually a tidier solution.

Security

• Use key-based login. Tunnels are only as secure as your SSH access. Turn off password login and log in only with a key; the steps are in our What is SSH? article.
• Use the local address. Leave tunnels on 127.0.0.1, as they are by default; that way, other devices on the same network can't use your tunnel.
• Turn off unnecessary forwarding. You can turn off forwarding on the server for users who don't use tunnels. In the sshd_config file, for a specific user or group:

  Match User sftp-only
      AllowTcpForwarding no


• Don't expose services. The real benefit of a tunnel is never exposing services such as databases and panels to the internet at all. Make sure these services only listen on 127.0.0.1; we cover port security in our What is a port? article.
